10R Moving Head Hybrid
Mode NO : Hotbeam280
Channels mode：16/24CH
Light Source
Lamp: Yodn280W;
Optical System
Beam angel : 2.5～20°;
Dimmer : 0-100% l inear adjustment ;
Gobo Wheels
Fixed gobo : 14 gobo + white
Rotation gobo: 9 gobo+ white,changeable;
Gobo size diameter:14.9mm ,image diameter:13mm;
Color Wheels
13 colors+white
Prism System
8 facet prism+ 6 linear prism ,Frost function;
Control & Screen
Display: 2.2 inch screen display, can reverse 180°;
Electrical Info
Power: 110-240V,50/60Hz;
Total power: 470W;
PAN & TILT
Pan : 540°; 8Bit/16Bit ;
Tilt : 270°; 8Bit/16Bit ;
Size & Weight
Product size: 382x365x587 mm;
Flycaes: 960x510x740 mm;
Carton: 460x440x580 mm;
N.W: 16KG ;
G.W: 73 KG(with flycase 2 in 1);
G.W: 20KG(carton).
Why choose XMLITE
XMlite is fast developing company
In March 2010, XM only have 210 square meters factory on the ShiJing town. As the fast development, XM become to 750 m³, In 2010 July. However, when the time arrived November 2011, XM have another chance of become bigger again. Plant size enlarge to 2200 m³.The worker, as well, grows from 20 to 50. On 2013 year, we have arrive 120 staff, and 6000 square meters.
XMlite a reliable factory
XMlite is the first factory, who take 3 years guarantee as the after sell service. In China, there is over 100 user scenarios, In worldwide, there is over 20 countries have customers. XM light only produce two model of beam light( beam200 , and beamspot ). XM try to maximize the sales. XM only sell the product he own produce.
High Quality of the raw material , make the stable product
XMlite ‘s market position is high cost –effective. Every spare parts picked up from highlevel supplier. The mass purchase quantity make our spare part’s cost islower than our competitor. Low cost enlarge our sale amount , sale’s increase regurgitation-feedingour cost.
XM have professional research group , skillful engineer .Perfect qualityand good after sell service , will be bring profit for customers. XM alsoaccept the OEM service ,which have good reputation during all customers.
XMlite is one of the biggest moving head beam producer factory in Guangzhou.
We have customers from all over the world as following:
Argentina, Australia, Bolivia, France, Greece, India, Indonesia, Israel, Italy, Kuwait, Malaysia, Mexico, Pakistan, Philippines, Poland, Portugal, Saudi Arabia, Singapore, Slovakia, South Korea, Spain, Sri-lanka, Turkey, U.S.A , Russia and Vietnam.
After-sale Service commitment
1 When the products had the technical problems during use, we will give timely answer once get the inform or arrange the technicals give the service to door..
2 We offer 3-year free warranty (In the first year, all the cost for warranty is paid by our factory, including the freight which for the broken products reback to the factory and the spare parts sent to the customers. And the next 2years, we will offer the spare parts for free)
Remarks: The warranty does not cover the light source.
XMlite also produce:,Moving Head Beam 200,Moving Head Beam 230w,LED Beam Moving Head,2R Beam Moving Head,280W Beam Moving Head Light(hot beam) and 280W spot Moving head light( beamspot)
Bulb model: OSRAM HRI 280W
Wffect wheel: 6-facet linear prism + 8-facet circular prism
Color wheel: 13 color
Gobo: 14 fixed gobo + 9 Rotation gobo
Power: 470W
IP lever: IP20
Voltage:
Size: 19KG
Function: beam spot wash zoom
Carton size:
